Steering Tie Rod End

A steering tie rod end is a crucial component of a vehicle's steering system. It is part of the linkage that connects the steering rack or steering box to the steering knuckle or spindle on each front wheel. The tie rod end is responsible for transmitting the steering input from the driver to the wheels, allowing for the turning and maneuvering of the vehicle.

The tie rod end consists of a threaded stud, a ball joint, and a housing. The threaded stud is connected to the steering linkage, while the ball joint connects to the steering knuckle or spindle. The housing provides protection and support for the ball joint.

As the driver turns the steering wheel, the motion is transferred to the steering linkage and eventually to the tie rod end. The ball joint allows for the articulation and movement required for the wheels to turn and follow the desired direction. Over time, the tie rod end can wear out due to constant use, exposure to road conditions, and general wear and tear.

When a tie rod end is worn or damaged, it can cause various steering-related issues. Some common symptoms of a faulty tie rod end include:
1. Loose or imprecise steering: You may notice excessive play or a loose feeling in the steering wheel. It can be challenging to maintain a straight line while driving, and the vehicle may wander or pull to one side.

2. Vibrations or shaking: A worn tie rod end can result in vibrations or shaking of the steering wheel, especially at higher speeds.

3. Uneven tire wear: If the tie rod end is not functioning correctly, it can cause uneven tire wear. You might notice excessive wear on the inner or outer edges of the tires.

4. Clunking or knocking sounds: A damaged tie rod end can produce clunking or knocking sounds when turning the steering wheel or going over bumps.

If you experience any of these symptoms, it is essential to have your vehicle inspected by a qualified mechanic. They can assess the condition of the tie rod ends and determine if they need to be replaced. It is generally recommended to replace tie rod ends in pairs to ensure balanced steering performance.

Regular maintenance and inspections of the steering system can help identify potential issues before they become severe. It's important to address any problems with the tie rod ends promptly to maintain the safety and performance of your vehicle's steering system.

Product Parameter

Number	Product Number	Product Type	UNIT	Specification	Quantity/Pieces
1	BJ130	STEERING TIE ROD END	Pair	M18*15.6	18
2	BJ1041.HF6700	STEERING TIE ROD END	Pair	M20*18	18
3	NJ131|EQ1060|1061	STEERING TIE ROD END	Pair	M18|22|24*17.6	18
4	QINGLING700P	STEERING TIE ROD END	Pair	M24*20	18
5	CA1046|Liberation Baling	STEERING TIE ROD END	Pair	M30*15.6|18	8
6	Hongta Jinling	STEERING TIE ROD END	Pair	M24*15.6	8
7	EQ140	STEERING TIE ROD END	Pair	M27*20	12
8	Steyr	STEERING TIE ROD END	Pair	M30*23.5	12
9	HF6853 Small Auman 5 series	STEERING TIE ROD END	Pair	M30*20	12
10	Three T Kings	STEERING TIE ROD END	Pair	M27*20	12
11	RED ROCK-HOWO	STEERING TIE ROD END	Pair	M30*27.1	8
12	CA141（SMALL J6)	STEERING TIE ROD END	Pair	M30*22	6
13	CA151	STEERING TIE ROD END	Pair	M30*23.5	6
14	16T Orway	STEERING TIE ROD END	Pair	M36*27.5	6
15	HF6782|6800	STEERING TIE ROD END	Pair	M33*19.6	8
16	North Benz|Yutong King Long	STEERING TIE ROD END	Pair	M30*29|28.1	8
17	King Long6791	STEERING TIE ROD END	Pair	M30*20	6
18	King Long6792	STEERING TIE ROD END	Pair	M30*20	6
19	new dragon	STEERING TIE ROD END	Pair	M36*28	8
20	United Heavy Truck	STEERING TIE ROD END	Pair	M30*27.1	6
21	Ankai Golden Dragon 6120|Universiade	STEERING TIE ROD END	Pair	M36|38*27.1	6
22	Tyrannosaurus	STEERING TIE ROD END	Pair	M38*27.1	8
23	FAW Hanwei	STEERING TIE ROD END	Pair	M36*23.5	6
24	Qingdao Hanwei	STEERING TIE ROD END	Pair	M30*23.5	6
25	New Dawei	STEERING TIE ROD END	Pair	M30*23.5	4
26	EQ153	STEERING TIE ROD END	Pair	M44*27.1	4
27	Dongfeng Tianlong	STEERING TIE ROD END	Pair	M44*27.1	4
28	EQ153（Disposable）	STEERING TIE ROD END	Pair	M44*27.1	4
29	AUMAN ETX	STEERING TIE ROD END	Pair	M44*27|23.5	3
30	Galfa M42	STEERING TIE ROD END	Pair	M42*27.1	3
31	AUMAN M42|M44	STEERING TIE ROD END	Pair	M44|M42*23.5	3
32	Hualing M42	STEERING TIE ROD END	Pair	M44*29	3
33	HualingM56	STEERING TIE ROD END	Pair	M56*29|27	3
34	Liberation J6	STEERING TIE ROD END	Pair	M42*27.5	2
35	HOWO-DELONG	STEERING TIE ROD END	Pair	M38*23.5	8
36	Denon	STEERING TIE ROD END	Pair	M33*27	8
37	Valin M40	STEERING TIE ROD END	Pair	M40	6
38	CA151	STEERING TIE ROD END	Pair	M30*23.5	8
